Blog 36: 5/22/23: Aviation overview; the North American / Rockwell XB-70 Valkyrie, the Bomber that Never Was

XB-70 Valkyrie in photo op formation before its horrible end.

Welcome back to Brooke In The Air!

Today's analysis is a special request from a fan: the XB-70 Valkyrie experimental bomber.

In the 1950s, the US Air Force wanted a bomber that could outfly enemy (Soviet) ground-based air defenses and aerial interceptors, the only viable modes of air defense at the time.

The North American Aviation (NAA) XB-70 Valkyrie was the prototype version of the planned B-70 nuclear-armed, deep-penetration supersonic strategic bomber for the United States Air Force Strategic Air Command (SAC, the firyect predecessor to today's Global Strike Command).

Designed in the late 1950s by North American Aviation, the six-engined Valkyrie was capable of cruising for thousands of miles at Mach 3+ while flying at 70,000 feet, an unprecedented 21,000 meters.

At these speeds, it was expected that the B-70 would be practically immune to interceptor aircraft, the only truly effective weapon against bomber aircraft at the time. The bomber would spend only a brief time over a particular radar station, flying out of its range before the controllers could position their fighters in a suitable location for an interception. Its high speed made the aircraft difficult to see on radar displays and its high-altitude and high-speed capabilities could not be matched by any contemporaneous Soviet interceptor or fighter aircraft.

The introduction of the first Soviet surface-to-air missiles in the late 1950s put the near-invulnerability of the B-70 in doubt. In response, the United States Air Force began flying its missions at low level, where the missile radar's line-of-sight (LOS) was limited by terrain. In this low-level penetration role, the B-70 offered little additional performance over the venerable subsonic B-52 it was meant to replace, while being far more expensive with shorter range. As this tactic was not what the B-70 was designed for, alternate missions were proposed, but these were of limited scope and capability.

With the advent of now-common intercontinental ballistic missiles (ICBMs) during the late 1950s, crewed nuclear bombers were increasingly seen as obsolete and a relic of the past.

The USAF eventually gave up fighting for its military production and the B-70 program was canceled in 1961. Development was then turned over to a research program to study the effects of long-duration high-speed and high-altitude flight by NASA.

North American Aviation XB-70A Valkyrie in mid-flight during high altitude supersonic tests.

As such, two prototype aircraft, designated XB-70A, were built; these aircraft were used for supersonic test-flights during 1964–69. In 1966, one prototype crashed after colliding with a smaller aircraft while flying in close formation; the remaining Valkyrie bomber is on display at the National Museum of the United States Air Force in Dayton, Ohio.

The Last Remaining XB-70 on Display Currently at the National Museum of the United States Air Force at Wright-Patterson Air Force Base, Dayton, Ohio.

BACKGROUND / INITIAL IDEAS

In an offshoot of Boeing's MX-2145 crewed boost-glide bomber project, Boeing partnered with RAND Corporation in January 1954 to explore what sort of bomber aircraft would be needed to deliver the various contemporary nuclear weapons under development. At the time, nuclear weapons weighed several tons, and the need to carry enough fuel to fly that payload from the continental United States to the Soviet Union demanded large bombers. Boeing and RAND also concluded that after the release of the bombs, the aircraft would need supersonic speed to escape the critical blast-radius.

The aviation industry had been studying this problem for some time. From the mid-1940s, there was interest in using nuclear-powered aircraft in the bomber role. Yes, you read that right. Nuclear -powered aircraft. In a conventional jet engine, thrust is provided by heating air using jet fuel and accelerating it out a nozzle.

Boeing’s Conceptual Design. Unselected.

Yet, in a nuclear engine, heat is supplied by a reactor, whose consumables last for months instead of hours. Most designs also carried a small amount of jet fuel for use during high-power portions of flight, such as takeoffs and high-speed dashes.

NUCLEAR AIRCRAFT CONSIDERATION

The U.S. Air Force (USAF) followed these developments closely, and in 1955 issued General Operational Requirement No. 38 for a new bomber, combining the payload and intercontinental range of the B-52 with the Mach 2 top speed of the Convair B-58 Hustler. The new bomber was expected to enter service in 1963. Both nuclear and conventional designs were considered. The nuclear-powered bomber was organized as "Weapon System 125A" and pursued simultaneously with the jet-powered version, "Weapon System 110A.”

The USAF Air Research and Development Command's (ARDC) requirement for WS-110A asked for a chemical-fuel bomber with Mach 0.9 cruising speed and "maximum possible" speed during a 1,900 km entrance and exit from the target. The requirement also called for a 23,000 kg payload and a combat radius of 7,400 km. The Air Force formed similar requirements for a WS-110L intercontinental reconnaissance system in 1955, but this was later canceled in 1958 due to better options. In July 1955, six contractors were selected to bid on WS-110A studies. Boeing and North American Aviation submitted proposals, and on 8 November 1955 were awarded contracts for Phase 1 development. Spoiler alert: none of these requirements were achievable without sacrificing others.

In mid-1956, initial designs were presented by the two companies. Boron-based Zip fuel was to be used in the afterburners to improve range by 10 to 15 percent over conventional fuel. Both designs featured huge wing-tip fuel tanks that could be jettisoned when their fuel was depleted before a supersonic dash to the target. The tanks also included the outer portions of the wing, which would also be jettisoned to produce a smaller wing suitable for supersonic speeds. Both became trapezoidal wings after ejection, at that time the highest performance planform known. They also featured flush cockpits to maintain the highest fineness ratio possible in spite of its effects on visibility.

North American Aviation (NAA) Initial design concept for the XB-70. Despised by advisor General LeMay.

The two designs had takeoff weights of approximately 340,000 kg with large fuel loads. The Air Force evaluated the designs, and in September 1956 deemed them too large and complicated for operations.

General Curtis LeMay, Senior USAF technical and strategic advisor and WWII veteran bomber commander, at the time, was dismissive, claiming with derision, "this is not an airplane, it's a three-ship formation." The USAF ended initial Phase 1 development in October 1956 and instructed the two contractors to continue design feasibility studies.

NEW ADVANCEMENTS AND TECHNIQUES

While the original proposals were being studied, advances in supersonic flight were proceeding rapidly. The narrow delta was establishing itself as a preferred planform for supersonic flight, replacing earlier designs like the swept-wing and trapezoidal layouts seen on designs like the Lockheed F-104 Starfighter and the earlier WS-110 concepts. Engines able to cope with higher temperatures were also under development, allowing for sustained supersonic speeds.

This work led to an interesting discovery: when an engine was optimized specifically for high speed, it burned perhaps twice as much fuel at that speed than when it was running at subsonic speeds. However, the aircraft would be flying as much as four times as fast. Thus its most economical cruise speed, in terms of fuel per mile, was its maximum speed. This was entirely unexpected and implied that there was no point in the dash concept; if the aircraft was able to reach Mach 3, it may as well fly its entire mission at that speed. The zip fuel idea was discarded entirely. The question remained whether such a concept was technically feasible, but by March 1957, engine development and wind tunnel testing had progressed enough to suggest that it was.

XB-70 Valykrie, powered down during testing

Parked on the tarmac at Edwards Air Force Base (AFB), California.

While WS-125A was ultimately discarded, WS-110 was redesigned to fly at Mach 3 for the entire mission. Zip fuel was finally retained for the engine's afterburner to increase range. Both North American and Boeing returned new designs with very long fuselages and large delta wings. The designs differed primarily in engine layout; the NAA (North American) design arranged its six engines in a semi-circular duct under the rear fuselage, while the Boeing design used separate podded engines located individually on pylons below the wing, like the B-58 Hustler. North American scoured available literature to find any additional advantage. This led them to an obscure report by two experts, who wrote a report in 1956 titled "Aircraft Configurations Developing High Lift-Drag Ratios at High Supersonic Speeds"

This is known today as compression lift, and the idea was to use the shock wave generated off the nose or other sharp points on the angular aircraft as a source of high-pressure air. By carefully positioning the wing in relation to the shock, the shock's high pressure could be captured on the bottom of the wing and thereby generate additional lift. To take maximum advantage of this effect, they redesigned the underside of the aircraft to feature a large triangular intake area far forward of the engines, better positioning the shock in relation to the wing. The six individually-podded engines were repositioned, three in each of two separate ducts, under the fuselage. North American improved on the basic concept by adding a set of drooping wing-tip panels that were lowered at high speed. This helped trap the shock wave under the wing between the downturned wing tips. It also added more vertical surface to the aircraft to maintain directional stability at high speeds. NAA's solution had an additional advantage, as it decreased the surface area of the rear of the wing when the panels were moved into their high-speed position. This helped offset the natural rearward shift of the center of pressure, or "average lift point", with increasing speeds. Under normal conditions this caused an increasing nose-down trim, which had to be offset by moving the control surfaces, increasing drag. When the wing tips were drooped, the lifting area of the wings was lessened, moving the lift forward and reducing trim drag.

The buildup of heat due to skin friction during sustained supersonic flight had to be addressed. During a Mach 3 cruise, the aircraft would reach an average of 230 °C (Celsius) with leading edges reaching 330 °C, and up to 540 °C in engine compartments. NAA proposed building their design out of sandwich panels, with each panel consisting of two thin sheets of stainless steel brazed to opposite faces of a honeycomb-shaped foil core. Expensive titanium, which had to be acquired, ironically enough, from the Soviet Union - the enemy it was intended to operate against - would be used only in high-temperature areas like the leading edge of the horizontal stabilizer, and the nose. To cool the interior, the XB-70 pumped fuel en route to the engines through heat exchangers.

On 30 August 1957, the Air Force decided that enough data were available on the NAA and Boeing designs that a competition could begin. On the 18th of September, the U.S. Air Force issued final operational requirements that called for a cruising speed of Mach 3.0 to 3.2, an over-target altitude of 70,000–75,000 ft (21,000–23,000 m), a range of up to 10,500 miles (16,900 km), and a gross weight not to exceed 490,000 pounds (220,000 kg). The aircraft would have to use the hangars, runways and handling procedures used by the B-52. On 23 December 1957, the North American proposal was declared the winner of the competition, and on 24 January 1958, a contract was issued for Phase 1 development.

XF-108 Rapier, proposed long-range supersonic interceptor meant to accompany and share engine parts with the much larger XB-70 Valkyrie bomber, note the internal weapons bay now common in the 21st century on the F-22A Raptor and F-35A/B/C Lightning II. The XF-108 never saw production. Artists’ official USAF portrait rendition.

In February 1958, the proposed bomber was designated B-70, with the prototypes receiving the "X" experimental prototype designation. The name "Valkyrie" was the winning submission in early 1958, selected from 20,000 entries in a USAF "Name the B-70" contest. The Air Force approved an 18-month program acceleration in March 1958 that rescheduled the first flight to December 1961. But in late 1958 the service announced that this acceleration would not be possible due to lack of funding. In December 1958, a Phase II contract was issued.

The mockup of the B-70 was reviewed by the Air Force in March 1959. Provisions for air-to-surface missiles and external fuel tanks were requested afterward. At the same time, North American was developing the XF-108 supersonic interceptor (see above). To reduce program costs, the F-108 would share two of the engines, the escape capsule, and some smaller systems with the B-70. In early 1960, North American and the USAF released the first drawing of the XB-70 to the public.

THE EVER-INCREASING ANTI-AIR MISSILE PROBLEM

The B-70 was planned to use a high-speed, high-altitude bombing approach that followed a trend of bombers flying progressively faster and higher since the start of crewed bomber use.

Only two weapons proved effective against bombers: fighter aircraft and anti-aircraft artillery or triple-A (AAA). Flying higher and faster made it more difficult for both; higher speeds allowed the bomber to fly out of range of the weapons more quickly, while higher altitudes increased the time needed for fighters to climb to the bombers, and greatly increased the size of the AAA weapons needed to reach those altitudes. As early as 1942, German flak commanders had already concluded that AAA would be essentially useless against jet aircraft, and began development of guided missiles to fill this role. Most forces reached the same conclusion soon after, with both the US and UK starting missile development programs before the second world war ended.

Interceptor aircraft with ever-improving performance remained the only effective anti-bomber weapons by the early 1950s, and even these were having problems keeping up with the latest designs; Soviet interceptors during the late 1950s could not intercept the high-altitude U-2 Dragonlady reconnaissance aircraft, despite its relatively low speeds. It was later discovered that flying faster also made radar detection much more difficult due to an effect known as the blip-to-scan ratio, and any reduction in tracking efficiency would further interfere with the operation and guidance of fighters. The introduction of the first effective anti-aircraft missiles (AAM) by the late 1950s changed this picture dramatically.

U2 Dragonlady in flight, courtesy USAF Public Relations dept.

Missiles could stand ready for immediate launch, eliminating operational delays like the time needed to get the pilot into the cockpit of a fighter. Guidance did not require wide-area tracking or calculation of an intercept course: a simple comparison of the time needed to fly to the altitude of the target returned the required deflection. Missiles also had greater altitude capability than any aircraft and improving this to adapt to new aircraft was a low-cost development path. The US was aware of Soviet work in the field, and had reduced the expected operational lifetime of the U-2, knowing that it would become vulnerable to these missiles as they were improved. To add proof to this statement, in 1960, a U-2 flown by CIA pilot Gary Powers was shot down by one of the earliest Soviet guided air-defense missiles, the S-75 Dvina, known in the West as the SA-2 Guideline.

Faced with this increasingly difficult problem, military doctrine had already started shifting away from high-altitude supersonic bombing toward low-altitude penetration. Radar is line-of-sight, so aircraft could dramatically shorten detection distances by flying close to the Earth and hiding behind terrain. Missile sites spaced to overlap in range when attacking bombers at high altitudes would leave large gaps between their coverage for bombers flying at lower levels. With an appropriate map of the missile sites, the bombers could fly between and around the defenses. Additionally, early missiles generally flew unguided for a period of time before the radar systems were able to track the missile and start sending it guidance signals. With the Soviet SA-2 Guideline missile, this minimum altitude was measured at roughly 610 meters.

Mikoyan-Gurevich MiG-23 Flogger-B on Display at the National Museum of the History of Ukraine in the Second World War, in Kyiv, Ukraine (prior to the Russian invasion of 2022)

Flying at low-level provided protection against fighters as well. Radars of the era did not have the ability to “look down”; if a higher altitude aircraft's radar was aimed down to detect targets at a lower altitude, the reflection of the ground would overwhelm the signal returned from a target. An interceptor flying at normal altitudes would be effectively blind to bombers far below it. The interceptor could descend to lower altitudes to increase the amount of visible sky, but doing so would limit its radar range in the same way as the missile sites, as well as greatly increasing fuel use and thus reducing mission time. The Soviet Union would not introduce an interceptor with “look-down/shoot-down” capability until 1972 with the so-named (by NATO) “High Lark” radar system AKA the RP-23 Sapfir in the MiG-23M with the NATO reporting name “Flogger-B”, and even this model had very limited capability showing how the USSR lagged behind the West and especially the United States in terms of technological capabilities.

The “High-Lark” or RP-23 Sapfir was the first look-down/shoot-down airborne intercept radar system developed for and exclusively for the Soviet Air Forces. In short, the look-down/shoot-down capability means the given radar can track and guide a weapon to an air target that (as seen by the radar) is silhouetted against the ground.

Strategic Air Command (SAC) found itself in an uncomfortable position; bombers had been tuned for efficiency at high speeds and altitudes, performance that had been purchased at great cost in both engineering and financial terms. Before the B-70 was to replace the B-52 in the long-range role, SAC had introduced the B-58 Hustler to replace the Boeing B-47 Stratojet in the medium-range role. The problem was, the Hustler was expensive to develop and purchase, and required enormous amounts of fuel and maintenance in comparison to the B-47. It was estimated that it cost three times as much to operate as the much larger and longer-ranged B-52.

The B-70, designed for even higher speeds, altitudes and range than the B-58, suffered even more in relative terms. At high altitudes, the B-70 was as much as four times as fast as the B-52, but at low altitudes it was limited to only Mach 0.95, only modestly faster than the B-52 at the same altitudes yet low-altitude bombing was becoming more effective and strategically en vogue. The B-70 (XB-70) also had a smaller bombload and shorter range. Its only major advantage would be its ability to use high speed in areas without missile cover, especially on the long journey from the US to USSR. The value was limited; the USAF's doctrine stressed that the primary reason for maintaining the bomber force in an era of ICBMs was that the bombers could remain in the air at long ranges from their bases and were thus immune to sneak attack. In this case, the higher speed would be used for only a short period of time between the staging areas and the Soviet coastline before descending to low-level for the bombing run itself.

Adding to the problems, the zip fuel program was canceled in 1959. After burning, the fuel turned into liquids and solids that increased wear on moving turbine engine components. Although the B-70 was intended to use th Boron-based Zip only in the afterburners, and thus avoid this problem, the enormous cost of the zip program for such limited gains led to its cancellation. This by itself was not a fatal problem, however, as newly developed high-energy fuels like specialized JP-6 were available to make up some of the difference. Most of the range lost in the change from Zip fuel was restored by filling one of the two bomb bays with a fuel tank. However, yet another problem arose when the XF-108 Rapier program was canceled in September 1959, which ended the shared development that benefited the North American Aviation XB-70 program.

DOWNSIZING, CAMPAIGN PROMISES & SUBSEQUENT CANCELLATION

At two secret meetings on 16 and 18 November 1959, the Chairman of the Joint Chiefs of Staff, Air Force General Nathan Twining, recommended the Air Force's plan for the B-70 to reconnoiter and strike rail-mobile Soviet ICBMs, but the Chief of Staff of the Air Force, General Thomas White, admitted the Soviets would "be able to hit the B-70 with rockets" and requested the B-70 be downgraded to "a bare minimum research and development program" at $200 million for fiscal year 1960 (equivalent to $1.8 billion in 2023 US dollars, adjusting for inflation). President Eisenhower responded and agreed that the reconnaissance and strike mission was "crazy" since the nuclear mission was to attack known production and military complexes, and emphasized that he saw no need for the B-70 since the ICBM is "a cheaper, more effective way of doing the same thing". Eisenhower also identified that the B-70 would not be in manufacturing until "eight to ten years from now" and "said he thought we were talking about bows and arrows at a time of gunpowder when we spoke of bombers in the missile age." In December 1959 the Air Force announced the B-70 project would be cut to a single prototype, and most of the planned B-70 subsystems would no longer be developed. Interest subsequently increased due to the politics of presidential campaign of 1960.

XB-70 on the Taxiway, Day of the First Flight

A central plank of candidate John F. Kennedy's campaign was that Eisenhower and the Republicans were weak on defense, a major point of contention at the time, and fashioning himself as a “Cold Warrior.” Kennedy pointed to the B-70 and Eisenhower’s as a stark example of his argument for defense. He told a San Diego audience near NAA facilities, "I endorse wholeheartedly the B-70 manned aircraft." Kennedy also made similar campaign claims regarding other aircraft: near the Seattle-Boeing plant, he affirmed the need for additional upgraded B-52 Stratofortresses and in Fort Worth, Texas campaign event he praised the B-58 Hustler. Yet this was a ploy for votes, and it worked. The Air Force then changed the program to full weapon development and awarded a contract for an XB-70 prototype and 11 YB-70s in August 1960. In November 1960, the B-70 program received a $265 million (equivalent to $2.4 billion in 2023 US dollars) appropriation from Congress for Fiscal Year 1961. Richard Nixon, trailing in his home state of California, also publicly endorsed the B-70, and on 30 October Eisenhower helped the Republican campaign with a pledge of an additional $155 million ($1.4 billion today-2023 dollars) for NAA’s ongoing XB-70 development program.

Upon taking office in January of 1961, Kennedy was informed that the missile gap was an illusion. On 28 March 1961, after $800 million (equivalent to $7.3 billion in today’s dollars) had been spent on the B-70 program, Kennedy canceled the project as "unnecessary and economically unjustifiable" because it "stood little chance of penetrating enemy defenses successfully." In short, the missile gap was the perceived superiority of the number and power of the USSR's missiles in comparison with those of the U.S. (a lack of military parity for sufficient Mutually Assured Destruction, or otherwise adherence to the M.A.D. strategic doctrine). The gap in the ballistic missile arsenals did not exist except in exaggerated estimates, made by a Committee in 1957 and in United States Air Force (USAF) figures. Even the contradictory Central Intelligence Agency figures for the USSR's weaponry, which showed a clear advantage for the US, were far above the actual count. Like the bomber gap of only a few years earlier, it was soon demonstrated that the gap was entirely fictional. After Congress approved $290 million ($2.6 billion today) of B-70 "add-on" funds to the President's 12 May 1960 modified FY 1961 budget, the Administration decided on a "Planned Usage" of only $100 million ($910 million in 2023) of these funds. The Department of Defense (DoD)subsequently presented data to Congress that the B-70 would add little performance for the high taxpayer cost. There is no record of what the excess funds were used for, or where these funds went.

However, after becoming the new Air Force Chief of Staff in July 1961, Curtis LeMay puzzlingly increased his B-70 advocacy, including interviews for August Reader's Digest and November Aviation Week articles, and allowing a 25 February General Electric tour at which the press was provided artist conceptions of, and other info about, the B-70. Congress had also continued B-70 appropriations in an effort to resurrect bomber development. After Secretary of Defense Robert McNamara explained again to the House Armed Services Committee (HASC) on 24 January 1962 that the B-70 was unjustifiable, LeMay subsequently argued for the B-70 to both the House and Senate committees—and was chastised by McNamara on 1 March. By 7 March 1962, the HASC, 21 of whose members had B-70 work in their districts, had written an appropriations bill to "direct"—by law—the Executive Branch to use all of the nearly $500 million (equivalent to $4.5 billion today) appropriated for the RS-70. Secretary McNamara was unsuccessful with an address to the HASC on 14 March, but a 19 March 1962 11th hour White House Rose Garden agreement between Kennedy and HASC chairman Carl Vinson retracted the bill's language and the bomber remained canceled.

THE EXPERIMENTAL ERA & INFLUENCING THE FUTURE

The XB-70s were intended to be used for the advanced study of aerodynamics, propulsion, and other subjects related to large supersonic transports. The crew was reduced to only the two pilots, as a navigator and a bombardier were not needed for this research role. The production order was reduced to three prototypes in March 1961 with the third aircraft to incorporate improvements from the previous prototype. The order was later reduced to two experimental XB-70As, named Air Vehicle 1 and 2 (AV-1 and AV-2). XB-70 No. 1 was completed on 7th of May 1964, and rolled out on 11th of May 1964 at the USAF’s Plant 42 at Palmdale, California. One report stated "nothing like it existed anywhere". AV-2 was completed on 15 October 1964. The manufacture of the third prototype (AV-3) was canceled in July 1964 before completion. The first XB-70 carried out its maiden flight in September 1964 and many more test flights followed. The first XB-70 carried out its maiden flight in September 1964 and many more test flights followed.

Russian Air Force Mikoyan-Gurevich MiG-25 high-altitude long-range interceptor

(Credit: By Leonid Faerberg (transport-photo.com) - http://www.airliners.net/photo/Russia---Air/Mikoyan-Gurevich-MiG-25.../0412379/L/, GFDL 1.2, https://commons.wikimedia.org/w/index.php?curid=5493431)

The data from the XB-70 test flights and aerospace materials development were used in the later B-1 bomber program (now known as the B- Lancer), the American supersonic transport (SST) program (American version of the British-French Concorde which was ultimately canceled), and via espionage, the Soviet Union's Tupolev Tu-144 SST program (Soviet copy of the Concorde, failed and crashed in the prototype stage). The development of the Lockheed U-2 Dragonlady and the SR-71 Blackbird reconnaissance aircraft, as well as the XB-70, prompted Soviet aerospace engineers to design and develop their high-altitude and high-speed MiG-25 interceptor, NATO reporting name “Foxbat”.

TECHNICAL DESIGN OF THE VALKYRIE

The Short-lived SM-64 Navaho Supersonic Intercontinental Cruise Missile by North American Aviation (NAA)

The Valkyrie was designed to be a high-altitude Mach 3+ bomber with six engines. Doctor Harrison Storms, PhD, et al., an engineer of Apollo Command Module design fame shaped the aircraft with a canard surface and a delta wing, which was built largely of stainless steel, sandwiched honeycomb (just like it sounds) panels, and illicitly-gained titanium. The XB-70 was designed to use supersonic technologies developed for the Mach 3 SM-64 Navaho, a short-lived Intercontinental cruise missile project by North American Aviation, as well as a modified form of the Navaho's inertial guidance system. (See picture below)

The XB-70 used compression lift, which resulted from a shock wave generated by the leading edge of the engine intake splitter below the apex of the wing. At Mach 3 cruising speed, the shock wave is bent back about 65 degrees and the wing is superimposed on the shock system which has a pressure 40 pounds per square foot higher under the aircraft than in front of the shock. The compression lift provided five percent of the total lift. Camber was added to the wing leading edge inboard of the folding tips to improve subsonic handling and reduce supersonic drag. The outer portions of the wings were hinged to pivot downward by 65 degrees, acting as a type of variable-geometry wingtip device. This increased the aircraft's directional stability at supersonic speeds, shifted the center of pressure to a more favorable position at high speeds, and caused the shock originating at the intake splitter to reflect from the vertical tip surface giving additional compression lift.

For definition, in aeronautical engineering, camber is the asymmetry between the two acting surfaces of an airfoil, with the top surface of a wing (or correspondingly the front surface of a propeller blade) commonly being more convex (positive camber). An airfoil that is not cambered is called a symmetric airfoil. The benefits of cambering were discovered and first utilized by pioneering aeronautical engineer George Cayley in the early 19th century. Camber is usually designed into an airfoil to maximize its lift coefficient. This minimizes the stalling speed of aircraft using the airfoil. An aircraft with cambered wings will have a lower stalling speed than an aircraft with a similar wing loading and symmetric airfoil wings. An aircraft designer may also reduce the angle of attack of the outboard section of the wings. This ensures that, as the aircraft approaches the stall, the wing root stalls before the tip, giving the aircraft resistance to spinning and maintaining aileron effectiveness close to the stall.

Like a number of other delta-wing aircraft designed for supersonic speeds (Concorde, Tu-144, FD2, etc.), the Valkyrie needed a feature to improve the pilot's view during nose-high low-speed flight and on the ground. An outer windshield and ramp, which could be lowered, was provided enabling viewing through the fixed cockpit windshield. With the ramp raised into its high-speed position, the forebody was more streamlined. Rain removal and windshield anti-ice was accomplished by utilizing 316 °C bleed air from the engines, an innovative solution. The lower forward section of the aircraft included a packed radar bay, and production machines were to be equipped with a refueling receptacle on the upper surface of the forward fuselage for mid-air refueling.

EQUIPPED ENGINES

General Electric YJ93-GE-3 specially designed turbojet engines, specifically for the XB-70 - On display at the Nation al Museum of the US Air Force in Dayton, Ohio

The XB-70 was equipped with a sextet of six General Electric YJ93-GE-3 turbojet engines, which used JP-6 jet fuel, specially formulated for the mission requirements. The engine was stated to be in the "30,000-pound class", but actually produced 120 kN with afterburner and 89 kN - kilonewtons -without afterburner. The Valkyrie used fuel for cooling; it was pumped through heat exchangers before reaching the engines. To reduce the likelihood of autoignition, nitrogen was injected into the JP-6 during refueling, and the "fuel pressurization and inerting system" vaporized a 320 kg supply of liquid nitrogen to fill the fuel tank vent space and maintain tank pressure.

OPERATIONS AND SHORT-LIVED HISTORY

The XB-70's maiden flight was on 21st of September, 1964. In the first flight test, between Palmdale's Plant 42 and Edwards AFB, both in California, one engine had to be shut down shortly after take-off, and an undercarriage malfunction warning meant that the flight was flown with the undercarriage down as a precaution, limiting speed to 630 km/h (390 mph) – about half the previously planned speed. During landing, the rear wheels of the port side main gear locked, the tires ruptured, and a fire started.

The Valkyrie first became supersonic (Mach 1.1) on the third test flight on 12 October 1964, and flew above Mach 1 for 40 minutes during the following flight on 24 October. The wing tips were also lowered partially in this flight. See initial picture.

XB-70 No. 1 (AV-1) surpassed Mach 3 on 14 October 1965 by reaching Mach 3.02 at 21,000 meters or 70,000 feet. The first aircraft was found to suffer from weaknesses in the honeycomb panels, primarily due to inexperience with fabrication and quality control of this new material.

On two occasions, the prized honeycomb panels failed and were torn off during supersonic flight, necessitating a Mach 2.5 limit being placed on the aircraft.

The deficiencies discovered on AV-1 were almost completely solved on the second XB-70, AV-2, which first flew on 17 July 1965. On 3 January 1966, XB-70 No. 2 (AV-2) attained a speed of Mach 3.05 while flying at 22,000 m (70,000 feet) AV-2 reached a top speed of Mach 3.08 and maintained it for 20 minutes on 12 April 1966.

On 19 May 1966, AV-2 reached Mach 3.06 and flew at Mach 3 for 32 minutes, covering 3,900 km in 91 minutes of total flight, from takeoff to landing.

The Valkyrie experimental bomber still holds several flight records.

XB-70 performance records

  • Longest flight: 3:40 hours - 6 January 1966

  • Fastest speed: 2,020 mph (3,250 km/h) - 12 January 1966

  • Highest altitude: 74,000 ft (23,000 m) - 19 March 1966

  • Highest Mach number: Mach 3.08 - 12 April 1966

  • Sustained Mach: 332 minutes - 19 May 1966

  • Mach 3 total: 108 minutes over 10 flights

A joint NASA/USAF research program was conducted from the 3rd of November, 1966 to the 31st of January, 1967, for measuring the intensity and signature of sonic booms for the National Sonic Boom Program (NSBP). Testing was planned to cover a range of sonic boom overpressures on the ground similar to but higher than those anticipated from the proposed American SST (see above). In 1966, AV-2 was selected for the program and was outfitted with test sensors. It flew the first sonic boom test on 6 June 1966, attaining a speed of Mach 3.05 at 72,000 ft (22,000 m).

Two days later, AV-2 crashed following a mid-air collision with an F-104 interceptor while flying in a multi-aircraft formation (see first picture). Sonic boom evaluations and further testing continued with XB-70A #1 AKA AV1 for a short while before being discontinued.

The second flight research program (NASA NAS4-1174) investigated "control of structural dynamics" from the 25th of April, 1967 through the XB-70's last flight in early 1969. At high-altitude and high-speed, the XB-70A experienced unwanted changes in altitude. NASA testing from June of 1968 included two small vanes on the nose of AV-1 for measuring the response of the aircraft's stability augmentation system (SAS).

AV-1 flew a total of 83 flights before it's forced retirement. The XB-70's last supersonic flight took place on 17 December 1968. On 4 February 1969, AV-1 took its final flight to Wright-Patterson Air Force Base for museum display (now the National Museum of the United States Air Force) where AV1 can still be seen today. Flight data was collected on this subsonic trip. North American Aviation-then-North American-Rockwell (now Boeing) completed a four-volume report on the B-70 that was published by NASA in April of 1972, in the midst of the Vietnam War.

THE ACCIDENT

XB-70 Flying in Formation seconds before the crash. The F-104 is the red-tailed aircraft on the right side. Photographed from the chase plane.

On the 8th of June 1966, XB-70A No. 2 was in close formation with four other aircraft (an F-4 Phantom, an F-5 Tiger, a T-38 Talon, and an F-104 Starfighter) for a photoshoot at the behest of General Electric, manufacturer of the engines of all five aircraft. After the photoshoot, the F-104 drifted into the XB-70's right wingtip, flipped and rolled inverted over the top of the Valkyrie, before striking the bomber's vertical stabilizers and left wing. The F-104 then exploded, destroying the Valkyrie's vertical stabilizers and damaging its left wing. Despite the loss of both vertical stabilizers and damage to the wings, the Valkyrie flew straight for 16 seconds before it entered an uncontrollable spin and crashed north of Barstow, California.

NASA Chief Test Pilot Joe Walker (F-104 Starfighter pilot) and Carl Cross (XB-70 co-pilot) were killed. Al White (XB-70 pilot) ejected, sustaining serious injuries, including the crushing of his arm by the closing clamshell-like escape crew capsule moments prior to ejection.

The USAF summary report of the accident investigation stated that, given the position of the F-104 relative to the XB-70, Walker, the F-104 pilot, would not have been able to see the XB-70's wing, except by uncomfortably looking back over his left shoulder. The report said that it was likely that pilot Walker maintained his position by looking at the fuselage of the XB-70, forward of his position. The F-104 was estimated to be 21 m. Or 70 feet to the side of the fuselage of the XB-70 and 3.0 m or 9 feet below. The report concluded that from that position, without appropriate sight cues, Walker was unable to properly perceive his motion relative to the Valkyrie, leading to his aircraft drifting into the XB-70's wing. The accident investigation also pointed to the wake vortex from the XB-70's right wingtip as the reason for the F-104's sudden roll over and into the bomber.

8 June, 1966 Crash between an F-104 Starfighter interceptor and the XB-70A AKA AV-2. The fireball is the F-104, the XB-70 would fly on for an additional 16 seconds before going into a fatal “death spiral” over Barstow, California.

SPECIFICATIONS AND CHARACTERISTICS

General characteristics

  • Crew: 2

  • Length: 185 ft 0 in (56.39 m)

  • Wingspan: 105 ft 0 in (32.00 m)

  • Height: 30 ft 0 in (9.14 m)

  • Wing area: 6,297 sq ft (585.0 m2)

  • Airfoil: Hexagonal; 0.30 Hex modified root, 0.70 Hex modified tip.

  • Empty weight: 253,600 lb (115,031 kg)

  • Gross weight: 534,700 lb (242,536 kg)

  • Max takeoff weight: 542,000 lb (245,847 kg)

  • Fuel capacity: 300,000 pounds (140,000 kg) / 46,745 US gal (38,923 imp gal.)

  • Powerplant: 6 × General Electric YJ93 afterburning turbojet, 19,900 lbf (89 kN) thrust each dry, 28,000 lbf (120 kN) with afterburner.

    PERFORMANCE SPECIFICATIONS

  • Performance

    • Maximum speed: 1,787 kn (2,056 mph, 3,310 km/h)

    • Maximum speed: Mach 3.1

    • Cruise speed: 1,738 kn (2,000 mph, 3,219 km/h)

    • Combat range: 3,725 nmi (4,287 mi, 6,899 km)

    • Service ceiling: 77,350 ft (23,580 m)

    • Lift-to-drag: about 6 at Mach 2

    • Wing loading: 84.93 lb/sq ft (414.7 kg/m2)

    • Thrust/weight ratio: 0.314


THANK YOU FOR JOINING ME ON THIS WEEK'S AVIATION DEEP DIVE! JOIN ME NEXT WEEK ON BROOKE IN THE AIR, AND CONSIDER JOINING MY PATREON! LINKED BELOW, SEE MY VLOGS FOR TRAVEL GOODNESS!
